Transformers | Current - Measurement | Split-Core

KBPN 52

The KBPN 52 is a Split-Core current transformer, thermoplastic for measurement in low voltage (0.72kV) systems. Primary current: 400A to 1,000A according to the model. Product dimension: 158 x 127 x 36mm. Windows dimension 83.5x53mm. Accuracy class of 0.6% or 1.2% and a maximum Burden of 2.0, 2.5, 5 or 10VA.

For further information, see the product datasheet and Transformers Catalog.

Categories: , , .
Prev
Next
DEMONSTRATIVE VIDEO

What is a Current Transformer? Watch our videos for further explanation of the Kron Current Transformer product line, operation and installation.
